ProLight Therapy Pen

The ProLight Therapy Pen is a powerful yet compact handheld device designed for precise and targeted light therapy application.

Equipped with five LEDs, it utilises various light wavelengths to address both the dermal layer and deeper tissues. The 460nm blue light possesses antibacterial properties, which can aid in wound healing and combat conditions like mud fever. Meanwhile, the 630nm and 660nm red light focus on the surface, while the 850nm and 940nm infrared light penetrate deeper to target soft tissue.

Each setting will last for 3 minutes.

Each wavelength serves a distinct purpose, enhancing the overall effectiveness of the treatment.

Here's a breakdown of the key wavelengths and their respective benefits:

• Red Light (630nm 660nm): Targets the surface of the skin.
• Infrared (850nm 940nm): Penetrates deeper to relieve muscle tension, support joint mobility, and reduce pain.
• Blue Light (460nm): Supports skin health and fights bacteria, making it effective for treating wounds and skin irritations.
• Enhanced Blood Circulation: Red and infrared light therapy stimulates blood flow, promoting faster healing and recovery.
• Pain and Inflammation Reduction: Effective in alleviating muscle soreness, joint pain, and reducing inflammation.
• Improved Muscle Function: Regular use can lead to increased muscle relaxation and flexibility, benefiting overall performance.
• Non-Invasive: A natural and drug-free way to support your horse’s wellbeing.

Technical Specifications

• Dimensions: 123 mm (Length) x 30 mm (Diameter)
• Weight: 135 grams including one battery
• Wavelengths: 460nm (Blue), 630nm, 660nm (Red Light);

850nm, 940nm (Near-Infrared Light)

• Irradiation: over 120 mW/cm²
• Battery: Rechargeable Lithium Battery (18650)
• LED Lifespan: Approximately 50,000 hours

Operating Instructions

• Battery Installation
• Unscrew the battery cap located at the end of the pen.
• Insert a fully charged battery with the positive (+) end facing inward.
• Screw the battery cap back securely.

Mode Selection

• Press the power button to turn on the device. The default mode activates all LEDs in continuous light mode.
• Press the power button again to activate only red LEDs (630 nm and 660 nm) and near-infrared (850 nm, 940 nm).
• Press again to activate only blue LEDs (460 nm).
• Press once more to turn off.
• To activate pulse mode, hold the power button for more than 5 seconds in any of the above modes, and the LEDs will start pulsing. The same sequence will apply to pulse mode (all LEDs on, Red/Infrared on, Blue LED on).

Treatment Application

• Ensure the horse’s skin is clean and dry.
• Hold the device approximately 1 inch away from the targeted area.
• Move the pen slowly over the treatment area in a circular motion.
• Each session duration is 3 minutes per area.
• Do not exceed 15 minutes of total treatment per session.

Warranty Information

The ProLight Therapy Pen comes with a 2-year warranty covering manufacturing defects. This warranty does not cover damage resulting from misuse, unauthorised modifications, or accidents. For warranty claims, please retain your proof of purchase and contact our customer service department.

Please Note: Light therapy devices are designed to work alongside medications and are not a replacement for standard medical procedures.
